Features & Applications
Features:
Dual Independent Signal Channels
Multi-Output Options (0-20mA, 4-20mA, 0-±5V, 0-±10V)
High Accuracy (<0.05% FS)
Wide Operating Temperature (-30°C to 60°C)
Selectable Response Frequency (100Hz or 5kHz)
Zero & Span Adjustment
Drives Up to 4 Load Cells (350Ω) per Channel
Compact Size (118x88x30mm), IP64 Protection
Applications:
Industrial Process Monitoring & Control
Multi-Sensor Test & Measurement Systems
Precision Load & Force Measurement
Data Acquisition Systems Requiring Flexible Outputs
Specifications
| Power supply | DC18~30V |
| Signal input range | 0.4~6mV/V |
| Excitation voltage | 5VDC±2% ,100mA |
| Accuracy | 0.05%F.S. |
| Current output | 0~20mA/4-20mA |
| Voltage output | 0~±5V/V/0~±10V |
| Number of load cells | Each channel drives 4pcs load cells 3500 |
| Dimensions | 118x88x30mm |
| Temperature operating | -30~60℃ |
| Frequency response | 100HZ/5KHZ(option) |
| Protection | IP64 |
Selection Table
| AM-106 | 100HZ | AM-106H | 5000H |
Size
Load Cell Packaging & Shipping Standards
At Brans, we implement rigorous packaging protocols to guarantee your load cell arrives in perfect condition:
1. Multi-Layer Protective Packaging
• Primary Protection: Each unit is vacuum-sealed in moisture-proof barrier film
• Secondary Cushioning: High-density EPS foam molded to the load cell's contours
• Tertiary Security: Reinforced double-wall corrugated shipping container
2. Advanced Shock Mitigation System
• Multi-axis vibration damping with PE bubble wrap
• Edge protectors for all sensitive components
• "Fragile" and "This Side Up" labeling per ISTA standards
3. Secure Transit Assurance
• Tamper-evident security tape with company logo
• Barcoded shipping labels with QR tracking
• Certified weighing at dispatch for freight verification
4. Premium Logistics Network
• Partnered with DHL/FedEx/UPS for global coverage
• Real-time tracking updates via SMS/email
• 24/7 shipment monitoring by our logistics team
Post-Delivery Protocol:
• Recommended inspection within 48 hours
• Damage claims must include original packaging photos
